Other Control Si34-803_B
161 Function
• Cancel to set the slave unit 2 from operation
prohibition mode, set No. 40 of Setting mode 2 to
"OFF".
(Procedure)
(1) Press and hold the MODE button (BS1) for a period
of 5 seconds or more.
(2) Press the SET button (BS2) 40 times.
(3) Press the RETURN button (BS3) once.
(4) Press the SET button (BS2) once.
(5) Press the RETURN button (BS3) twice.
(6) Press the MODE button (BS1) once.
5.3 Demand Operation
In order to save the power consumption, the capacity of outdoor unit is saved with control
forcibly by using “Demand 1 Setting” or “Demand 2 Setting”.
To operate the unit with this mode, additional setting of “Continuous Demand Setting” or
external input by external control adaptor is required.
5.4 Heating Operation Prohibition
Heating operation is prohibited above 24°C ambient temperature.
LED display (
h
:ON
h
h
:OFF
l
:Blink)
H1P
----
H7P
(Factory setting)
h
hhhhhh
hhhhhh
hh
h
hh
hhh
hhh
h
hhhh
hhhh
l
h
h
h
hhhhh
hhhhh
l
h
hhhhhh
hhhhhh
hh
hhh
hhhh
hhhh
Set item Condition Content
Demand 1 Mode 1 The compressor operates at approx. 60% or less of rating.
Mode 2 The compressor operates at approx. 70% or less of rating.
Mode 3 The compressor operates at approx. 80% or less of rating.
Demand 2 The compressor operates at approx. 40% or less of rating.
Demand 3 Forced thermostat OFF.
