Si34-803_B Troubleshooting by Indication on the Remote Controller
Troubleshooting 280
3.17
“
E1
”
Outdoor Unit: PCB Defect
Remote
Controller
Display
E1
Applicable
Models
RXYQ5P(A)~54P(A)
Method of
Malfunction
Detection
Check data from E²PROM
Malfunction
Decision
Conditions
When data could not be correctly received from the E²PROM
E²PROM : Type of nonvolatile memory. Maintains memory contents even when the power
supply is turned OFF.
Supposed
Causes
Defect of outdoor unit PCB (A1P)
Troubleshooting
Turn off the power once and
turn ON again.
Return to normal?
YES
YES
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Check
if inside/outside
relay wires of
outdoor main PCB is
disconnected.
Connect the inside/outside
relay wires correctly.
Replace the outdoor main
PCB (A1P).
External factor other than
malfunction (for example,
noise etc.).
NO
NO
