List of Electrical and Functional Parts Si34-803_B
413 Appendix
Parts Name
Symbol
Model
Remark
FXSQ
20MVE
FXSQ
25MVE
FXSQ
32MVE
FXSQ
40MVE
FXSQ
50MVE
FXSQ
63MVE
FXSQ
80MVE
FXSQ
100MVE
FXSQ
125MVE
Remote
Controller
Wired Remote
Controller
BRC1D61 / BRC1E61
Option
Wireless Remote
Controller
BRC4C62
Motors
Fan Motor M1F
AC 220~240V 50Hz
1
φ50W 1φ65W 1φ85W
1
φ
125W
1φ225W
Thermal Fuse 152°C
Thermal protector
135°C : OFF 87°C : ON
Drain Pump M1P
AC220-240V (50Hz)
PLD-12230DM
Thermal Fuse 145°C
Thermistors
Thermistor (Suction Air)
R1T
ST8601-4
φ4 L800
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-7
φ8 L1600
20kΩ (25°C)
Thermistor (Heat
Exchanger)
R2T
ST8602A-6
φ
6 L1250
20k
Ω (25°C)
Others
Float Switch S1L FS-0211B
Fuse F1U 250V 5A
φ5.2
Transformer T1R TR22H21R8
Parts Name
Symbol
Model
Remark
FXMQ
20PVE
FXMQ
25PVE
FXMQ
32PVE
FXMQ
40PVE
FXMQ
50PVE
FXMQ
63PVE
FXMQ
80PVE
FXMQ
100PVE
FXMQ
125PVE
FXMQ
140PVE
Remote
Controller
Wired Remote
Controller
BRC1D61 / BRC1E61
Wireless Remote
Controller
BRC4C65
Motors
Fan Motor M1F DC280V 140W 8P DC373V 350W 8P
Drain Pump M1P
AC220-240V (50/60Hz)
PLD-12230DM
Thermal protector 145°C
Thermistors
Thermistor (Suction Air)
R1T
ST8601-3
φ L630
20kΩ (25°C)
Thermistor (for Heat
Exchanger High Temp.)
R3T
ST8605-14
φ8 L1000
20kΩ (25°C)
Thermistor (for Heat
Exchanger)
R2T
ST8602A-6
φ8 L1250
20kΩ (25°C)
Others
Float Switch S1L FS-0211B
Fuse (A1P) F1U 250V 3.15A
Fuse (A2P, A3P)
F3U·
F4U
250V 6.3A
Fuse (A2P) F2U 250V 5A —
