Combination of Outdoor Units Si34-803_B
7 General Information
High COP Series (Energy Saving Series)
Note: For multiple connection of 16HP system or more, an optional Daikin Outdoor Unit Multi
Connection Piping Kit is required.
System
Capacity
Number
of units
Module
Outdoor Unit Multi Connection
Piping Kit (Option)
8 1012141618
16HP 2 ●●
Heat Pump: BHFP22P100
18HP 2 ●●
24HP 3 ●●●
26HP 3 ●● ●
28HP 3 ●● ●
30HP 3 ●●●
32HP 3 ●●●
34HP 3 ●●●
36HP 3 ●●●
38HP 3 ●● ●
Heat Pump: BHFP22P151
40HP 3 ●● ●
42HP 3 ●● ●
44HP 3 ●●●
46HP 3 ●●●
48HP 3 ●●●
50HP 3 ●● ●
