User’s Manual of VC-810S / VC-810S48
21
3. SWITCH MANAGEMENT
This chapter describes how to manage the VDSL2 Switch. Topics include:
- Overview
- Management methods
- Assigning an IP address to the VDSL2 Switch
- Logging on to the VDSL2 Switch
3.1 Overview
This chapter gives an overview of switch management. The VDSL2 Switch provides a simply WEB browser interface.
Using this interface, you can perform various switch configuration and management activities, including:
System
Port Management
VLAN
Quality of Service
Multicast
Address Learning Table
Port Mirroring
Link Aggregation
Statistics
Storm Control
Please refer to the following Chapter 4 for more details.
3.2 Requirements
■ Network cables.
Use standard network (UTP) cables with RJ45 connectors.
■ Subscriber PC installed with Ethernet NIC (Network Card)
■ Workstations of subscribers running Windows 98/ME, NT4.0, 2000/2003/XP, MAC OS X or later, Linux, UNIX or
other platform compatible with TCP/IP protocols.
■ Above PC installed with WEB Browser and JAVA runtime environment Plug-in.
It is recommended to use Internet Explore 6.0 or above to access VDSL2 Switch.
