![Planet VC-810S [7/82] Ethernet interface](/views2/1071640/page7/bg7.png)
User’s Manual of VC-810S / VC-810S48
7
1.4 Product Features
VDSL2 Interfaces
8 x Spring terminal block connectors for VDSL2 connection
8 x Spring terminal block connectors for telephone/POTS connection
Built-in POTS splitter for each VDSL2 port
Link to VC-201 CPE Bridge
Auto-speed function for VDSL2 link (by distance and cable quality)
Ethernet Interface
1-Port Gigabit TP/SFP combo interface
Auto-MDI/MDI-X detection on Gigabit RJ-45 port
VDSL2 Features
Cost-effect VDSL2 link and central management solution
ITU-T G.993.2 VDSL2 standard
DMT (Discrete Multi-Tone) line coding VDSL
Up to 100/55Mbps asymmetric data rate
Copper wiring distance up to 1km
Selectable target data rate and target SNR margin
Build-in surge protection to against surge damage from high energy spike
Voice and data communication can be shared on the existing telephone wire simultaneously
Layer 2 Features
Complies with IEEE 802.3 10Base-T, IEEE 802.3u 100Base-TX, IEEE 802.3z 1000Base-SX/LX, IEEE 802.3ab
1000Base-T, IEEE 802.3x flow control, IEEE 802.1Q VLAN and 802.1p priority queuing
8K MAC address table, auto-ageing, 3.6Gbps backbone
IEEE 802.3x Full-duplex flow-control, back-pressure in half-duplex eliminate packets loss
High performance Store and Forward architecture, broadcast storm control, runt/CRC filtering eliminates
erroneous packets to optimize the network bandwidth
IEEE 802.1Q Tagged based VLAN and Port-Based VLAN
IEEE 802.1Q Tagged VLAN, supports tag insertion and removal, and up to 32 VLAN groups
Support up to 2 Trunk groups, each trunk for up to maximum 4 ports per group
Quality of Service
2 priority queues on all switch ports
Support QoS and bandwidth control (Rate Limit) on each VDSL port and GbE port
Traffic class assignment based on IP TOS/DSCP mode, 802.1p priority tag mode and Port-Based mode
Support for strict priority and Weighted Round Robin (WRR) CoS policies
Multicast
IGMP Snooping v1 and v2
Security
Port mirroring for dedicated port monitoring
MAC address based port security, unknown source MAC address will be ignored on a specified port
