User’s Manual of VC-810S / VC-810S48

Figure 3-2 Login screen

After a successful login, the main screen appears, the main screen displays the Switch status. The screen in Figure3-3

appears.

Figure 3-3 Web Login screen of VDSL2 Switch

1. For security reason, please change and memorize the new password after this first setup.

2. Only accept command in lowercase letter under web interface.
