User’s Manual of VC-810S / VC-810S48
33
While SNMP mode is selected, the displayed page includes the following configurable data
Object Description
• Mode To turn on or turn off the SNMP Trap function on the VDSL2 Switch.
• System Name The system name of the VDSL2 Switch which would show in the SNMP software.
• System Description
The system description of the VDSL 2 Switch which would show in the SNMP
software.
• System Contact
The contact person of the VDSL2 Switch which would show in the SNMP software.
• System Location
The system location of the VDSL2 Switch which would show in the SNMP software.
• Trap Destination IP
Enter the IP address to receive SNMP traps from this device. Enter 4 numbers
between 0 and 255 separated by periods.
The VDSL2 Switch supports SNMP System information read and SNMP Trap only. It is not
able to be management via SNMP SET command.
