User’s Manual of VC-810S / VC-810S48
9
Button
Reset Button for system reset and Reset to factory default
Layer 2 Function
Management Interface
Web Browser,
SNMP v1 and v2c, SNMP Trap*
PLANET Smart Discovery Utility
Port Configuration
Port Enable / Disable.
Flow Control Enable / Disable.
Bandwidth control on each port.
Port Status
VDSL2:
Display each port’s Status, Mode, Rate Limit and SNR
Gigabit Ethernet interface:
Display each port’s speed duplex mode, link status, Flow control status. Auto
negotiation status
Port Statistics
。 TX/RX packet/byte
。 CRC error
VLAN
Port-Based VLAN: up to 9 VLAN groups
IEEE 802.1Q Tagged Based VLAN: 4094 VLAN ID, up to 32VLAN groups
Link Aggregation
Supports 2 groups of 4-Port trunk
QoS
2 priority queues for three type of Class of Service
• Port-Based
• IEEE 802.1p priority tag
• TCP/IP header’s TOS/DSCP classifier
Weighted Round Robin queue scheduling
IGMP Snooping
v1 and v2, allow to disable or enable.
Bandwidth Control
Per port bandwidth control
Downstream: 1Mbps~100Mbps
Upstream: 1Mbps~60Mbps
Port Mirror
RX or TX
Security
Port Security (Per Port Disable MAC Address Learning )
SNMP MIBs
RFC-1213 MIB-II
RFC-2863 Interface MIB
Others
SNTP Client
MAC Address Table
Aging time: selectable Default Mode (300 Sec.) and Fast Mode (30 Sec.)
Standards Conformance
Regulation Compliance
FCC Part 15 Class A, CE
Protocols and Standards
Compliance
IEEE 802.3 10BASE-T
IEEE 802.3u 100BASE-TX
IEEE 802.3z Gigabit SX/LX
IEEE 802.3ab Gigabit 1000T
IEEE 802.3x Flow Control
IEEE 802.1p Class of service
IEEE 802.1Q VLAN Tagging
ITU-T
G.993.1 (VDSL)
G.997.1
G.993.2 VDSL2 (Profile 12a
Support), Annex A
RFC 768 UDP
RFC 793 TFTP
RFC 791 IP
RFC 792 ICMP
RFC 2068 HTTP
RFC 2030 SNTP
RFC 1112 IGMP versions 1
RFC 2236 IGMP versions 2
* The actual data rate will vary on the quality of the copper wire or coaxial cable and environment factors.
