EDUS391000-N_a Installation
Installation of Outdoor Units 39
(Refer to figure 3)
1. Indoor unit
2. Branch switch, ground leakage circuit breaker
3. Remote controller
4. COOL/HEAT selector
5. Personal computer or radio
2. When installing in locations where there is heavy snowfall, imple-
ment the following snow measures.
• Ensure the base is high enough that intakes are not clogged by
snow.
• Remove the rear intake grille to prevent snow from accumulat-
ing on the fins.
5. INSPECTING AND HANDLING THE
UNIT
• At delivery, the package should be checked and any damage
should be reported immediately to the carrier claims agent.
• When handling the unit, take into account the following :
1. Fragile, handle the unit with care.
Keep the unit upright in order to avoid compressor damage.
2. Decide on the transportation route.
3. If a forklift is to be used, pass the forklift arms through the large
openings on the bottom of the unit. (Refer to figure 4)
4. If hanging the unit, use a cloth sling to prevent damaging the unit.
Keeping the following points in mind, hang the unit following the
procedure shown in figure 5.
• Use a sling sufficiently strong to hold the mass of the unit.
• Use 2 belts of at least 27 ft long.
• Place extra cloth or boards in the locations where the casing
comes in contact with the sling to prevent damage.
• Hoist the unit making sure it is being lifted at its center of gravity.
5. After installation, remove the transportation brackets (yellow)
attached to the large openings. (Refer to figure 4)
(Refer to figure 4)
1. Packaging material
2. Forklift
3. Removal of shipping brackets
4.
Shipping bracket (Remove the brackets by pushing the
hook.)
(Refer to figure 5)
1. Belt sling
2. Wear plate
6. PLACING THE UNIT
• Make sure the unit is installed level on a sufficiently strong base to
prevent vibration and noise. (Refer to figure 6)
• The base should support the unit with the extent larger than
hatched area in figure 7.
If protective rubber is to be attached, attach it to the whole face of
the base.
• The height of the base should be at least 5-7/8 in. from the floor.
• Secure the unit to its base using foundation bolts. (Use four
commercially available M12-type foundation bolts, nuts, and
washers.)
• The foundation bolts should be inserted 13/16 in..
(Refer to figure 6)
1. Independent base (four corner type)
2. Independent base (with center support
type)
3. Beam base (Horizontal)
4. Beam base (Vertical)
5. Center of the product
(Refer to figure 7)
1. Foundation bolt point (φ9/16 in. dia, : 4positions)
2. (Depth of product)
3. (Inner dimension of the base)
4. (Outer dimension of the base)
• There are restrictions on the refrigerant pipe connecting order
between outside unit in the case of the multi system.
See “2-1 Combination” for detail.
• When installing on a roof, make sure the roof floor is strong
enough and be sure to water-proof all work.
• Make sure the area around the machine drains properly by setting
up drainage grooves around the foundation.
Drain water is sometimes discharged from the outside unit when it
is running.
• For anti-corrosion type, use nuts with resin washers. If the paint on
nut connections comes off, the anti-corrosion effect may decrease.
7. REFRIGERANT PIPING
• All field piping must be installed by a licensed refrigeration
technician and must comply with relevant local and national
regulations.
• After piping work is complete, do not under any circumstances
open the shutoff valve until “7. FIELD WIRING” and “10.
CHECKING OF DEVICE AND INSTALLATION CONDITIONS”
are complete.
• Do not use flux when brazing the refrigerant piping. Use the
phosphor copper brazing filler metal (B-Cu93P-710/795 : ISO
3677) which does not require flux.
(Flux has extremely negative effect on refrigerant piping systems.
For instance, if the chlorine based flux is used, it will cause pipe
corrosion or, in particular, if the flux contains fluorine, it will
damage the refrigerant oil.)
7-1 Selection of piping material and Refrigerant
branching kit
• Use only pipes which are clean inside and outside and which do
not accumulate harmful sulfur, oxidants, dirt, cutting oils, moisture,
or other contamination. (Foreign materials inside pipes including
oils for fabrication must be 9 mg/10 ft or less.)
• Use the following items for the refrigerant piping.
Material : Jointless phosphor-deoxidized copper pipe
Size : See “6-5 Example of connection” to determine the cor-
rect size.
Thickness : Select a thickness for the refrigerant piping which
complies with national and local laws.
• For piping work, follow the maximum tolerated length, difference in
height, and length after a branch indicated in the “6-5 Example of
connection”.
• Outside unit multi connection piping kit and refrigerant branching
kit (sold separately) are needed for connection of piping between
outside units (in case of multi system) and piping branches.
Use only separately sold items selected specifically according to
the outside unit multi connection piping kit, the refrigerant
branching kit selection in the “6-5 Example of connection”.
7-2 Protection against contamination
when installing pipes
Protect the piping to prevent moisture, dirt, dust, etc. from
entering the piping.
NOTE
Exercise special caution to prevent dirt or dust when passing pip-
ing through holes in walls and when passing pipe edges to the
exterior.
Model A (in.) B (in.)
72 · 96 · 108PA type 48-13/16 43-3/8
13/16 in.
Place Installation period Protection method
Outdoor
More than a month Pinch the pipe
Less than a month
Pinch or tape the pipe
Indoor Regardless of the period
Resin washers
