Troubleshooting by Remote Controller Si341009
95 Troubleshooting
Error code indication by outdoor unit P
C
B
<Monitor mode>
To enter the monitor mode, push the
MODE (BS1) button when in “Setting
mode 1”.
<Selection of setting item>
* Refer to Page 69 for Monitor mode.
* Refer to Page 69 for Monitor mode.
Push the SET (BS2) button and set
the LED display to a setting item.
<Confirmation of error 1>
Push the RETURN (BS3) button once
to display "First digit" of error code.
<Confirmation of error 2>
Push the SET (BS2) button once to
display "Second digit" of error code.
<Confirmation of error 3>
Push the SET (BS2) button once to
display "error location".
<Confirmation of error 4>
Push the SET (BS2) button once to
display "master or slave 1 or slave 2
or slave 3" and "error location".
Detail
description
on next
page.
Push the RETURN (BS3) button and
switches to the initial status of
“Monitor mode”.
* Push the MODE (BS1) button and
returns to “Setting mode 1”.
Error Error code
Description of error Description of error (PGF) Remote
controller
PCB abnormality Defective PCB E1
High pressure abnormality HPS activated E3
Actuation of low pressure sensor Defective Pe E4
Inverter compressor motor lock E5
STD compressor motor overcurrent/
Lock
STD 1 E6
STD 2
Outdoor unit fan motor abnormality Defective fan motor 1 E7
Defective fan motor 2
Electronic expansion valve coil
abnormality (Y1E-Y3E)
Y1E (Main) E9
Y2E (Refrigerant charging)
Y3E (Subcool heat exchanger)
Abnormal discharge pipe temperature Defective Td F3
Refrigerant overcharge Abnormal heat exchanger
temperature
F6
High pressure switch system
abnormality
H3
Abnormal outdoor fan motor signal Fan motor 1 positioning signal H7
Fan motor 2 positioning signal
Thermistor abnormality Thermistor (Outdoor air)
High pressure sensor abnormality J1
Current sensor abnormality STD 1 J2
STD 2
Thermistor abnormality (discharge
pipe)
For INV. compressor J3
For STD 1 compressor
For STD 2 compressor
Thermistor J4
Thermistor abnormality (suction pipe) J5
Thermistor abnormality (heat
exchanger deicer)
J6
Thermistor abnormality (liquid pipe) J7
Thermistor abnormality (receiver
liquid level, refrigerant regulator liquid
pipe, Receiver gas vent outlet)
J8
Thermistor abnormality (subcooling
heat exchanger outlet)
J9
High pressure sensor abnormality Defective S1NPH JA
Low pressure sensor abnormality Defective S1NPL JC
k
: ON
l
: Blink
h
: OFF
