Si341009 Troubleshooting by Remote Controller
Troubleshooting 142
2.32 Reverse Phase, Open Phase
Remote
Controller
Display
U1
Applicable
Models
RQYQ8-48PY1
Method of Error
Detection
The phase of each phase are detected by reverse phase detection circuit and right phase or
reverse phase are judged.
Error Decision
Conditions
When a power supply is reverse phase, or T phase is open phase.
Supposed
Causes
Power supply reverse phase
T phase open phase
Defective outdoor unit PCB (A1P)
Troubleshooting
Caution
Be sure to turn off power switch before connect or disconnect connector,
or parts damage may be occurred.
Rectify the open phase.
Requires inspection of field
power supply section.
There is an
open phase at the power
supply (T phase) terminal
section (X1M) of the
outdoor unit.
NO
Operation is
normal if one place
of power supply
line phase is
replaced.
NO
YES
YES
Reverse phase
Countermeasure of the problem is
completed by phase replacement.
Replace the outdoor unit PCB
(A1P).
