Test Operation Si341009
57 Test Operation
Check operation ends.
(Abnormal termination)
(Completed normally)
hkkhhhh
hhkhhhh
Check the malfunction
code on the indoor unit
remote controller, and
follow the instructions in
"Troubleshooting" to
correct the trouble.
After checking that the LED
display is normal, press the
TEST button (BS4) again.
Close the refrigerant
cylinder valve.
hlhhkkh
hlhhkkk
hlhkhhh
Waits for conditions to stabilize after restart.
Contamination operation (30 ~ 60
minutes)
Up to 1 hour may be required.
Automatic judgement of piping
length (approximately 10 minutes)
Checks the local piping length.
At the same time, performs a final check of the
refrigerant amount.
* To cancel check operation before it is completed, press the RETURN button (BS3).
