Daikin RQYQ22PY1 [45/194] Crankcase heater control
![Daikin RQYQ38PY1 [45/194] Crankcase heater control](/views2/1718492/page45/bg2d.png)
Si341009 Detailed Control Functions
Function 36
2. Detailed Control Functions
2.1 Stop Operation
2.1.1 Stop due to Malfunction
In order to protect compressors, if any of the abnormal state occurs, the system will make "stop with thermostat OFF"
and the malfunction will be determined according to the number of retry times.
(Refer to "Error code and description" (P.95~) of the troubleshooting for the items to determine the malfunction.)
2.1.2 When System is in Stop Mode
Both the master and slave units stop.
The four way valves both for heat exchanger switch and piping switch retain the condition before they were stopped.
2.2 Standby
2.2.1 Restart Standby
Used to forcedly stop the compressor for a period of 5 minutes, in order to prevent the frequent ON/OFF of the
compressor and equalize the pressure within the refrigerant system.
In addition, the outdoor fan carry out the residual operation for a while to suppress the acceleration of the pressure
equalizing and melting of the refrigerant to the evaporator.
2.2.2 Crankcase Heater Control
In order to prevent the refrigerant from melting in the compressor oil in the stopped mode, this mode is used to control
the crankcase heater.
Crankcase heater
OFF
Crankcase heater
ON
Discharge pipe
temperature < 70
˚C
Discharge pipe
temperature > 75
˚C
