SiBE041029_A Piping Diagrams
Appendix 115
RX50/60G3V1B
RX71GV1B, RX71GV1B9
OUTDOOR UNIT
HEAT EXCHANGER
7.9CuT
7.9CuT
7.9CuT
7.9CuT
7.9CuT
12.7CuT
CAPILLARY TUBE 1
CAPILLARY TUBE 2
CAPILLARY TUBE 3
CAPILLARY TUBE 4
7.9CuT
4.0CuT
7.9CuT
4.0CuT
7.9CuT
7.9CuT
REFRIGERANT FLOW
6.4CuT
COOLING
7.9CuT
4.0CuT
HEATING
6.4CuT
4.0CuT
6.4CuT
M
PROPELLER FAN
EV
FILTER
12.7CuT
6.4CuT
9.5CuT12.7CuT
RECEIVER
7.9CuT
12.7CuT
MUFFLER
MUFFLER
6.4CuT
7.9CuT
9.5CuT
MUFFLER
7.9CuT
12.7CuT
COMPRESSOR
HEAT
EXCHANGER
THERMISTOR
DISCHARGE PIPE
THERMISTOR
OUTDOOR TEMPERATURE
THERMISTOR
MUFFLER
WITH
FILTER
ELECTRONIC
EXPANSION
VALVE
FIELD PIPING
(6.4CuT)
FIELD PIPING
(
12.7
CuT)
LIQUID
STOP VALVE
GAS STOP VALVE
WITH SERVICE PORT
FOUR WAY
VALVE
ON: HEATING
3D080605
OUTDOOR UNIT
HEAT EXCHANGER
7.9CuT
7.9CuT
HEADER
7.9CuT
7.9CuT
7.9CuT
7.9CuT
7.9CuT
12.7CuT
7.9CuT
RECEIVER
4.0CuT
7.9CuT
EV
9.5CuT 9.5CuT9.5CuT 9.5CuT9.5CuT
FILTERFILTERDISTRIBUTOR
DC FAN MOTOR
M
9.5CuT
CAPILLARY TUBE
PROPELLER FAN
15.9CuT15.9CuT
7.9CuT
9.5CuT
7.9CuT
MUFFLER
9.5CuT
15.9CuT
15.9CuT
15.9CuT
7.9CuT
REFRIGERANT FLOW
COMPRESSOR
ACCUMULATOR ACCUMULATOR
COOLING
HEATING
15.9CuT 15.9CuT
OUTDOOR TEMPERATURE
THERMISTOR
HEAT EXCHANGER
(
CONDENSER
)
THERMISTOR
ELECTRONIC
EXPANSION
VALVE
4-WAY
VALVE
ON: HEATING
DISCHARGE PIPE
THERMISTOR
GAS LINE
STOP VALVE
LIQUID LINE
STOP VALVE
FIELD PIPING
LIQUID
(
6.4CuT
)
FIELD PIPING
LIQUID
(
15.9CuT
)
3D054593L
