Troubleshooting SiBE041029_A
62 Service Diagnosis
4.6 Refrigerant Shortage
Error Code
U0
Method of Error
Detection
Refrigerant shortage detection I:
Refrigerant shortage is detected by checking the input current value and the compressor
running frequency. If the refrigerant is short, the input current is lower than the normal value.
Refrigerant shortage detection II:
Refrigerant shortage is detected by checking the discharge pipe temperature and the opening of
the electronic expansion valve. If the refrigerant is short, the discharge pipe temperature tends
to rise.
Error Decision
Conditions
Refrigerant shortage detection I:
The following conditions continue for 7 minutes.
<RX50/60G2V1B, 71 class>
Input current
≤
A × output frequency + B
Output frequency > C
<RX50/60G3V1B>
Input current × input voltage
≤
D × output frequency + E
Output frequency > F
Refrigerant shortage detection II:
The following conditions continue for 80 seconds.
Opening of the electronic expansion valve ≥ G
Discharge pipe temperature > H × target discharge pipe temperature + J
If the error repeats, the system is shut down.
Reset condition: Continuous run for about 60 minutes without any other error
Supposed
Causes
Disconnection of the discharge pipe thermistor, indoor or outdoor heat exchanger thermistor,
room or outdoor temperature thermistor
Closed stop valve
Refrigerant shortage (refrigerant leakage)
Poor compression performance of compressor
Defective electronic expansion valve
A
(–)
B
(A)
C
(Hz)
RX50/60G2V1B 18/1000 0.7 55
71 class 27/1000 2.0 40
D
(–)
E (W) F (Hz)
RX50/60G3V1B 2000/256 –181 55
G (pulse) H (–) J (°C)
RX50/60G2V1B 480 255/256 cooling: 20, heating: 45
RX50/60G3V1B 480 128/128 cooling: 60, heating: 45
71 class 450 255/256 60
