SiBE041029_A Control Specification
Function and Control 35
3.3 Controls at Mode Changing / Start-up
3.3.1 Preheating Control
Outline The inverter operation in open phase starts with the conditions of the preheating command from
the indoor unit, the outdoor temperature, and the discharge pipe temperature.
Detail Outdoor temperature ≥ A°C → Control I
Outdoor temperature < A°C → Control II
Control I
ON condition
Discharge pipe temperature < B°C
OFF condition
Discharge pipe temperature > C°C
Radiation fin temperature ≥ 90°C
Control II
ON condition
Discharge pipe temperature < D°C
OFF condition
Discharge pipe temperature > E°C
Radiation fin temperature ≥ 90°C
3.3.2 Four Way Valve Switching
Outline In heating operation, current is conducted, and in cooling operation and defrost control, current
is not conducted. In order to eliminate the switching sound as the four way valve coil switches
from ON to OFF when the heating is stopped, the OFF delay switch of the four way valve is
carried out.
Detail OFF delay switch of four way valve:
The four way valve coil is energized for 150 seconds after the operation is stopped.
A(°C) B(°C) C(°C) D(°C) E(°C)
RX50/60G2V1B, 71 class 10 6 8 10.5 12
RX50/60G3V1B –2.5 0 2 10 12
