103
CONTROL COMMAND
14
D Command table (continued)
Cmd. Sub cmd. Data Description
16 42 00 Send/read Repeater tone OFF
01 Send/read Repeater tone ON
43 00 Send/read Tone squelch OFF
01 Send/read Tone squelch ON
44 00 Send/read Speech Compressor OFF
01 Send/read Speech Compressor ON
45 00 Send/read Monitor function OFF
01 Send/read Monitor function ON
46 00 Send/read VOX function OFF
01 Send/read VOX function ON
47 00 Send/read BK-IN function OFF
01 Send/read Semi BK-IN function ON
02 Send/read Full BK-IN function ON
48 00 Send/read Manual Notch function OFF
01 Send/read Manual Notch function ON
4C 00 Send/read VSC function OFF
01 Send/read VSC function ON
4F 00 Send/read Twin Peak Filter OFF
01 Send/read Twin Peak Filter ON
50 00 Send/read Dial Lock function OFF
01 Send/read Dial Lock function ON
55 00 Send/read 1st IF filter 15 kHz
01 Send/read 1st IF filter 6 kHz
02 Send/read 1st IF filter 3 kHz
56 00 Send/read DSP filter type SHARP
01 Send/read DSP filter type SOFT
57 00 Send/read manual notch width WIDE
01 Send/read manual notch width MID
02 Send/read manual notch width NAR
58 00 Send/read SSB transmit bandwidth WIDE
01 Send/read SSB transmit bandwidth MID
02 Send/read SSB transmit bandwidth NAR
17 see p. 107 Send CW messages
19 00 Read the transceiver ID
1A 00 see p. 108 Send/read memory contents
01 see p. 106 Send/read band stacking register contents
02 see p. 107 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
( AM: 00=200 Hz to 49=10 kHz; other than
AM modes: 00=50 Hz to 40/31=3600
Hz/2700 Hz)
04 00 to 13 Send/read the selected AGC time constant
( 00=OFF, AM: 01=0.3 sec. to 13=8.0 sec.;
other than AM modes: 01=0.1 sec. to
13=6.0 sec.)
05 0001 0000 to
0255
Send/read LCD contrast
(0000=0%(low)to0255=100%(high))
0002 0000 to
0255
Send/read LCD backlight brightness level
(0000=0%(dark)to0255=100%(bright))
0003 0000 to
0255
Send/read beep level
(0000=0%to0255=100%)
0004 00 Send/read beep level limit OFF
01 Send/read beep level limit ON
0005 00 Send/read confirmation beep OFF
01 Send/read confirmation beep ON
0006 00 Send/read band edge beep OFF
01 Send/read band edge beep ON
(Beep sounds with a default band)
02 Send/read band edge beep with user set-
ting ON
03 Send/read band edge beep with user set-
ting/TX limit ON
0007 0050 to
0200
Send/read beep audio frequency
(0050=500 Hz to 0200=2000 Hz)
Cmd. Sub cmd. Data Description
1A 05 0008 00 Send/read Auto selection for [RF/SQL]
01 Send/read SQL selection for [RF/SQL]
02 Send/read RF+SQL selection for [RF/SQL]
0009 00 Send/read Meter Peak Hold function OFF
01 Send/read Meter Peak Hold function ON
0010 00 Send/read Time-Out Timer (CI-V) OFF
01 Send/read 3 min. Time-Out Timer (CI-V)
02 Send/read 5 min. Time-Out Timer (CI-V)
03 Send/read 10 min. Time-Out Timer (CI-V)
04 Send/read 20 min. Time-Out Timer (CI-V)
05 Send/read 30 min. Time-Out Timer (CI-V)
0011 00 Send/read Quick Split function OFF
01 Send/read Quick Split function ON
0012 see p. 107 Send/read FM Split offset frequency (HF)
0013 see p. 107 Send/read FM Split offset frequency
(50 MHz)
0014 00 Send/read Split Lock function OFF
01 Send/read Split Lock function ON
0015 00 Send/read Tuner Auto Start OFF
01 Send/read Tuner Auto Start ON
0016 00 Send/read PTT Tune OFF
01 Send/read PTT Tune ON
0017 00 Send/read antenna selection OFF
01 Send/read manual antenna selection
02 Send/read auto antenna selection
0018 0000 to
0255
Send/read voice synthesizer level
(0000=0%to0255=100%)
0019 00 Send/read English selection for voice syn-
thesizer speech language
01 Send/read Japanese selection for voice
synthesizer speech language
0020 00 Send/read speech speed slow
01 Send/read speech speed fast
0021 00 Send/read S-meter level announcement
OFF
01 Send/read S-meter level announcement
ON
0022 00 Send/read operating mode announcement
(after pushing mode switch) OFF
01 Send/read operating mode announcement
(after pushing mode switch) ON
0023 00 Send/read number of memo pad channels
5
01 Send/read number of memo pad channels
10
0024 00 Send/read auto TS for [DIAL] OFF
01 Send/read auto TS for [DIAL] Low
02 Send/read auto TS for [DIAL] High
0025 00 Send/read Low selection for microphone
Up/Down speed
01 Send/read High selection for microphone
Up/Down speed
0026 00 Send/read Quick RIT/∂TX clear OFF
01 Send/read Quick RIT/∂TX clear ON
0027 00 Send/read Auto Notch selection for SSB
01
Send/read Manual Notch selection for SSB
02 Send/read Auto/Manual Notch selection
for SSB
0028 00 Send/read Auto Notch selection for AM
01 Send/read Manual Notch selection for AM
02 Send/read Auto/Manual Notch selection
for AM
0029 00 Send/read manual notch filter width pop-
up OFF
01 Send/read manual notch filter width pop-
up ON
