SET MODE
10
Tuner (PTT Start) 17. (Default: OFF)
Whenever you push [PTT], the internal or external an-
tenna tuner automatically starts tuning if the operating
frequencyischangedbymorethan1%fromthelast-
tuned frequency.
•OFF:Tuningstartsonlywhen[TUNER]ispushed.
•ON :(Internalantennatuner)Tuning startswhen
you push [PTT] on a new frequency, if the in-
ternal antenna tuner is ON.
(External antenna tuner) Tuning always starts
when you push [PTT] on a new frequency, re-
gardless of whether the external antenna tuner
is ON or OFF.
Tuner Preset Clear 18.
Select the desired antenna.
The selected antenna’s preset memory* is cleared by
holding down [CLR](F-4) for 1 second.
* The variable capacitor settings are memorized as a
preset point for each frequency range (100 kHz steps)
after the tuner matches an antenna.
•CLRANT1:Thepresetmemoryof[ANT1]’santenna
is cleared.
•CLRANT2:Thepresetmemoryof[ANT2]’santenna
is cleared.
[ANT] Switch 19. (Default: Auto)
Set the antenna switch function to Auto, Manual or OFF.
When you change the operating frequency, this func-
tion will automatically select the correct antenna, or you
must do it manually.
•OFF :[ANT•METER] does not function. The
[ANT1] connector is always selected.
•Manual :Youmustmanuallychangetheantennaby
pushing[ANT•METER].
•Auto :Theantennamemorizedbythebandmem-
ory is automatically selected. You can also
manually change the antenna by pushing
[ANT•METER].
SPEECH Level 20. (Default: 50%)
Adjustthespeechaudiooutputleveltobetween0%
(nooutput)and100%(maximumoutput).
SPEECH Language 21. (Default: English)
Select English or Japanese as the speech language.
SPEECH Speed 22. (Default: HIGH)
Select HIGH (faster) or LOW (slower) speech speed.
SPEECH S-Level 23. (Default: ON)
The signal level announcement with the voice synthe-
sizer can be turned ON or OFF.
•OFF:Thesignallevelisnotannounced.Operating
frequency is announced.
•ON :Thesignallevelandtheoperatingfrequency
are announced.
SPEECH [MODE] SW 24. (Default: OFF)
Turn the Operating Mode Speech function ON or
OFF.
When this function is ON, the selected operating mode
is verbally announced when a mode switch is pushed.
•OFF:TheoperatingmodeSpeechfunctionisOFF.
•ON :TheoperatingmodeSpeechfunctionisON.
Memopad Numbers 25. (Default: 5)
Set the number of available memo pads to 5 or 10.
See page 74 for details.
MAIN DIAL Auto TS 26. (Default: HIGH)
Set the Auto Tuning Step function for [DIAL]. When
rapidly rotating [DIAL], the tuning step automatically
changes as selected.
There are two types of auto tuning steps: LOW (Faster)
and HIGH (Fastest).
•OFF :AutotuningstepisturnedOFF.
•LOW :Approximately2timesfaster.
•HIGH:Approximately5timesfasterwhenthetuning
step is set to 1 kHz or smaller steps; approxi-
mately 2 times faster when the tuning step is
set to 5 kHz or larger steps.
