CONTROL COMMAND
14
• Memory keyer contents
Command : 1A 02
X
q: Channel data
w–&1: Text data
XXX
……
XX
01： M1
02： M2
03： M3
04： M4
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E
e.g., to send BT, enter ^BT
✱
2A Inserts contest number (can be
used for 1 channel only)
• CW message contents
Command : 17 Up to 30 characters
While transmitting in the CW mode, or if the Break-in
function is ON, the transceiver transmits CW code
when the PC sends Command 17.
To send CW messages, the following character codes
are used.
•Character’scode
Character ASCII code Description
0–9 30–39 Number
A–Z 41–5A Alphabetical characters
a–z 61–7A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
. 2E Symbol
– 2D Symbol
, 2C Symbol
: 3A Symbol
’ 27 Symbol
( 28 Symbol
) 29 Symbol
= 3D Symbol
+ 2B Symbol
” 22 Symbol
@ 40 Symbol
•“FF”stopssendingCWmessages.
•“^”isusedtotransmitastringofcharacterswith
no inter-character space.
• Split offset frequency setting
Command : 1A 05 0012, 0013
1 kHz digit: 0–9
100 Hz digit: 0 (fixed)
100 kHz digit: 0–9
10 kHz digit: 0–9
10 MHz digit: 0 (fixed)
1 MHz digit: 0–9
Direction:
00: + direction
01: – direction
q
0XXXXXX
we
0
r
• SSB transmission bandwidth setting
Command : 1A 05 0050, 0051, 0052
XX
Lower edge
Higher edge
Lower edge
0: 100Hz
1: 200Hz
2: 300Hz
3: 500Hz
Higher edge
0: 2500Hz
1: 2700Hz
2: 2800Hz
3: 2900Hz
• RX HPF and LPF settings in each
operating mode
Command : 1A 05 0045, 0053, 0058, 0063, 0064
XXXX
LPF (upper side)
HPF (lower side)
HPF
0: through
1 to 20: 100 to 2000 Hz
LPF
5 to 24: 500 to 2400 Hz
25: through
Set the LPF value larger than HPF one.
D Data content description (continued)
