PANEL DESCRIPTION

■ Function display (Continued)

!0 ALPHANUMERIC DISPLAY

 Displays an operating channel number, channel name, Set

mode contents, DTMF code, etc.

!1 KEY INDICATOR

 Indicate the programmed function of the front panel keys

([I], [II] and [III]).

See the operating guide for details of Analog and P25

Trunking/Conventional system operations. Consult your

Icom dealer or system operator for details concerning your

transceiver’s programming.

■ Programmable function keys

The following functions can be assigned to the following pro-

grammable function keys and switches;

[EMR], [Side1], [Side2], [Side3], [I], [II], [III], [Ω], [≈], [∫], [√],

[APP], [HOME], ABC switch and Toggle switch.

Consult your Icom dealer or system operator for details con-

cerning your transceiver’s programming.

If the key indicator shows the programmed function key

name, push the front panel key ([I], [II] or [III]) under the key

indicator to activate the programmed function.

( The function key name in parentheses in the following expla

nation is displayed for that key indicator; e.g. “UP”)

For ABC and Toggle switches:

The programmable key functions to ABC and Toggle switches

are limited. (See p. 10 for details.)

CH UP AND DOWN KEYS “UP” “DOWN”

➥ Push to select an operating channel. When [Rotary selec-

tor] selection mode is “operating channel,” this function is

not available.

➥ Push to select a scan group after pushing and holding

[Scan A Start/Stop]/[Scan B Start/Stop].
