![Icom IC-F9011 [28/32] D antennas](/views2/1074217/page28/bg1c.png)
7
OPTIONS
23
D BATTERY PACKS
Battery pack Voltage Capacity Battery life*
3
BP-254*
1
7.4 V 3040 mAh 9.5 hrs.
BP-237*
2
Battery case for
A6 × AA (LR6) alkaline
—*
4
*
1
The BP-254 meets IPX7* requirements for waterproof
protection. When it is connected, the transceiver corresponds
to IPX7.
*
2
The BP-237 meets IPX4* requirements for splash resistance.
When it is connected, the transceiver corresponds to IPX4.
*
3
When the power save function is turned ON, and the operating
periods are calculated under the following conditions;
TX : RX : standby = 5 : 5 : 90
*
4
Operating period depends on the alkaline cells used.
D CHARGERS
• BC-119N desktop charger + AD-110 charger adapter
+ BC-145 ac adapter
For rapid charging of battery pack. An AC adapter is sup-
plied with the charger depending on versions.
Charging time: approx. 4 hours when BP-254 is attached.
•
BC-121N multi-charger + AD-110 charger adapter (6
pcs.)
+ BC-157 ac adapter
For rapid charging of up to 6 battery packs (six AD-110s
are required) simultaneously. An AC adapter should be pur-
chased separately.
Charging time: approx. 4 hours when BP-254 is attached.
D CABLES
• CP-17L cigarette lighter cable
Allows charging of the battery pack through a 12 V cigarette
lighter socket. (For BC-119N)
• OPC-515L/OPC-656 dc power cables
Allows charging of the battery pack using a 13.8 V power
source instead of the AC adapter.
OPC-515L : For BC-119N
OPC-656 : For BC-121N
• OPC-1870/OPC-1871 zone copy cables
OPC-1870 : Portable to portable zone copy cable.
OPC-1871 : Portable to mobile zone copy cable.
See the operating guide for details.
D OPTIONAL UNITS
• UT-124R man down unit
Provides a measure of safety when working in a hazardous
environment, etc.
• UT-125 aes/des encryption unit
D ANTENNAS
• FA-S25V/FA-S65V/FA-S66V flexible antennas
FA-S25V: Frequency range 136–148 MHz
FA-S65V: Frequency range 148–160 MHz
FA-S66V: Frequency range 160–174 MHz
• FA-S67VC cut antenna
Frequency range 136–174 MHz
(Available in the near future)
