Icom IC-F9011 [18/32] Basic operation

■ Receiving and transmitting

NOTE: Transmitting without an antenna may damage the

transceiver. See page 1 for accessory attachments.

Receiving:

q Rotate [VOL] to turn the power ON.

w Push [CH Up] or [CH Down], or rotate [ROTARY SELEC-

TOR]* to select a channel, in sequence.

*Depending on the pre-setting.

e When receiving a call, adjust the audio output level to a

comfortable listening level.

Transmitting:

Wait for the channel to become clear to avoid interference.

q While pushing and holding [PTT], speak into the micro-

phone at a normal voice level.

w Release [PTT] to return to receive.

IMPORTANT: To maximize the audio quality of your signal;

1. Pause brieﬂy after pushing [PTT].

2. Hold the microphone 5 to 10 cm (2 to 4 inches) from

your mouth, then speak into the microphone at a nor-

mal voice level.

D Transmitting notes

• Transmit inhibit function

The transceiver has several inhibit functions which restrict

transmission under the following conditions:

- The channel is in mute condition (‘Inaudible’ condition;

“ ” does not appear.)

- The channel is busy.

- Un-matched (or matched) CTCSS is received.

(Depending on the pre-setting.)

- Un-matched (or matched) NAC is received*.

(Depending on the pre-setting.)

*Digital mode operation only.

- The selected channel is a ‘receive only’ channel.

• Time-out timer

After continuous transmission for the pre-programmed time

period, the time-out timer is activated, causing the trans-

ceiver to stop transmitting.

• Penalty timer

Once the time-out timer is activated, transmission is further

inhibited for a period determined by the penalty timer.

BASIC OPERATION
