!1 SQUELCH LEVEL INDICATOR
Shows the squelch level.
!2 VOLUME LEVEL INDICATOR
Sho
ws the volume level.
The bars appear in ascending order repeatedly when
the volume loud function is activated. (p. 12)
Blinks while the v
olume mute is activated. (p. 12)
!3 VOLUME LEVEL ADJUSTING INDICATOR (p. 11)
Blinks while adjusting the v
olume level.
This indicator and the volume level indicator appear
alternately while the volume level is turned up by the
noise detection function. (p. 20)
!4 SQUELCH LEVEL ADJUSTING INDICATOR (p. 12)
Blinks while adjusting the squelch level.
!5 CHANNEL NUMBER READOUT
Indicates the selected oper
ating channel number.
In the set mode, indicates the selected condition or
value. (p. 17)
!6 CHANNEL GROUP INDICATOR (p. 9)
appears when U.S.A.; appears when Interna-
tional;
appears when Canadian channel group is se-
lected each.
!7 WEATHER CHANNEL/WEATHER ALERT INDICATORS
(p. 9)
WX appears when the weather channel group is se-
lected.
WX ALT appears while the weather alert function is
activated; blinks when the alert tone is received.
!8 LOW POWER INDICATOR (p. 10)
LOW appears when low power is selected.
LOW blinks when switching forced low power mode
because of a high temperature error or low voltage.
7
3
PANEL DESCRIPTION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
5
16
