SUPPLIED ACCESSORIES AND ATTACHMENTS
2
■ Supplied accessories
Battery packHandstrap
Belt clip
Battery charger
(with 2 screws)
Antenna
AC adapter*
(BC-147SA or BC-
174E depending
on the version)
■ Attachments
D Flexible antenna
Connect the supplied flexible an-
tenna to the antenna connector.
CAUTION!
• NEVER carry the transceiver
by holding the antenna.
• T
ransmitting without an an-
tenna may damage the trans-
ceiver.
D Handstrap
Pass the handstrap through
the loop on the back side of
the transceiver as illustrated
at right. This facilitates carry-
ing.
D Belt clip
Attach/detach the belt clip to the transceiver as illustrated
below.
To attach the belt clip To detach the belt clip
Be careful!
Not to break
your nails.
w
q
* This illustration is described with the BC-147SA.
