Icom IC-M36 [34/36] Specifications and options
![Icom IC-M36 [34/36] Specifications and options](/views2/1074261/page34/bg22.png)
28
SPECIFICATIONS AND OPTIONS
12
■ Specifications
ï GENERAL
• Frequency coverage : Transmit 156.025–157.425 MHz
Receive 156.050–163.275 MHz
• Mode : FM (16K0G3E)
• Channel spacing : 25 kHz
• Power supply requirement : BP-251 and BP-252 only
• Current drain (at 7.4 V DC) : TX (6 W/1 W) 1.5 A/0.7 A typical
Max. audio
0.3 A typical
(internal speaker)
0.2 A typical
(external speaker)
Power save 10 mA typical
• Frequency stability : ±10 ppm
• Operating temperature range : –20°C to +60°C; –4°F to +140°F
• Dimensions : 62 (W)
× 139.5(H) × 43(D) mm
(projections not included)
2
7
⁄16(W) × 5
1
⁄2(H) × 1
11
⁄16(D) inch
• Weight : Approx. 295 g; 10.4 oz
(incl. BP-252, FA-SC58V and MB-109)
ï TRANSMITTER
• Output power (at 7.4 V DC) : 6 W (High) and 1 W (Low)
• Modulation system : Variable reactance frequency modulation
• Maximum frequency deviation : ±5 kHz
• Adjacent channel power : 70 dB
• Spurious emissions : –68 dBc typical
ï RECEIVER
• Receive system : Double-conversion superheterodyne
• Sensitivity (12 dB SINAD) : 0.25 µV typical
• Squelch sensitivity : 0.35 µV typical (at threshold)
• Intermodulation : 70 dB typical
• Spurious response : 70 dB typical
• Adjacent channel selectivity : 70 dB typical
• Audio output power (at 10% distortion)
Internal speaker : 0.70 W typical with a 16 Ω load
External speaker : 0.35 W typical with an 8 Ω load
All stated specifications are subject to change without notice or obligation.
■ Options
D BATTERY CASE AND PACK
• BP-251 battery case
Battery case for 5 × AAA (LR03) alkaline cells.
Output power level: 2 W
• BP-252 li-Ion battery pack
7.4 V/980 mAh Li-Ion battery pack.
D CHARGERS
• BC-173 desktop charger + BC-147SA/BC-174E ac adapter
Used for regular charging of battery pack. An AC adapter is supplied with
the charger depending on the version.
Charging time:
approx. 10 hours
• BC-162 desktop charger + BC-145* ac adapter
Used for rapid charging of battery pack.
Charging time: approx. 2 hours.
*Not supplied with some versions.
D BELT CLIPS
• MB-109 belt clip
The same as supplied with the transceiver.
D OTHER OPTIONS
• HM-165 speaker-microphone
Full sized speaker-microphone including an alligator clip to attach the mi-
crophone to your shirt, collar, etc. The HM-165 meets IPX7 requirements
for waterproof protection. However, once it has been dropped, the IP rating
cannot be guaranteed because of possible damage to it's case or the water-
proof seal.
• FA-SC58V antenna
Icom optional equipment is designed for optimal performance when used with
this transceiver. We are not responsible for the transceiver being damaged or
any accident caused when using non-Icom optional equipment.
