Icom IC-T2H [11/50] Panel description
![Icom IC-T2H [11/50] Panel description](/views2/1074440/page11/bgb.png)
7
2
PANEL DESCRIPTION
➥ In set mode or initial set mode, indicates the selected
item, condition, etc.
i BUSY AND S/RF INDICATORS (p. 12)
➥ “BUSY” appears when receiving a signal or when the
squelch is open.
➥ The S/RF indicators show the relative signal strength
while receiving and the output power when transmitting
(2 segments appear for low power and all segments ap-
pear for high power).
o LOW POWER INDICATOR (p. 12)
Appears when low output power is set.
!0 SKIP INDICATOR (p. 25)
Appears when the selected channel is set as a “skip” chan-
nel.
!1 MEMORY CHANNEL INDICATOR (p. 13)
Indicates the selected memory channel and other items
such as the call channel.
IC-T2H Manual 01.12.5 4:31 PM Page 7 (1,1)
