Icom IC-W32A [33/48] I full programmed scan
![Icom IC-W32A [33/48] I full programmed scan](/views2/1074461/page33/bg21.png)
8
SCAN OPERATION
29
■ Full/programmed scan
q Assign the main band to the desired display with [MAIN].
w Select VFO mode with [VFO].
e Make sure the squelch is set to the threshold point.
•Select automatic squelch (AT) or a level (SQ1–SQ8) where the
noise is muted. (p. 17)
r Push [(MAIN)SCAN] for 2 sec. to start the programmed
scan.
•Decimal point flashes while scanning.
•“P1” – “P5” flash to indicate which pair of scan edges is being
scanned.
•To change the scanning direction, rotate [DIAL].
•If the pocket beep function is activated, the transceiver automat-
ically selects the tone squelch function when a scan starts.
t Push [1] – [5] to select the desired scan range or push [0]
to select full scan.
y To stop the scan, push [
(VFO)CLR].
For programmed scan, scan edges must be programmed
in advance. Program scan edges in the same manner as
regular memory channels. (p. 22)
If the same frequencies are programmed into a pair of
scan edges, a programmed scan edge appears, such as
“P1,” but programmed scan does not proceed.
■ Memory scan
q Assign the main band to the desired display with [MAIN].
w Select memory mode with [MR].
e Make sure the squelch is set to the threshold point.
•Select automatic squelch (AT) or a level (SQ1–SQ8) where the
noise is muted. (p. 17)
r Push [(MAIN)SCAN] for 2 sec. to start the memory scan.
•To change the scanning direction, rotate [DIAL].
•If the pocket beep function is activated, the transceiver automat-
ically selects the tone squelch function when a scan starts.
t To stop the scan, push [(VFO)CLR].
