■ Receiving and transmitting
RECEIVING:
q Push [POWER] to turn the power ON.
w Push [CH UP] or [CH DN] to select a channel.
e When receiving a call, adjust the audio output level to a
comfortable listening level.
TRANSMITTING:
r Take the microphone off hook.
• The channel is busy when TX/RX indicator turns green.
- According to the trasceiver’s setting;
• 2-tone, 5-tone mute may be released. (The ‘audible’ condition is
selected)
• A priority channel may be selected automatically.
t Wait for the channel to become clear.
y Push the [CALL] key when initiating a call from your side.
- According to the trasceiver’s setting;
• Coded audio may be heard from the transceiver, then TX/RX
indicator turns green.
• This operation may not be necessary depending on your signal-
ing system. Ask your Dealer.
u While pushing and holding [PTT], speak into the micro-
phone at your normal voice level.
i Release [PTT] to receive.
IMPORTANT: To maximize the readability of your signal:
(1) Pause briefly after pushing [PTT]
(2) Hold the microphone 2 to 5 cm from your mouth, then
speak into the microphone at a normal voice level.
D Transmitting notes
• Transmit inhibit function
The transceiver has several inhibit functions which restrict
transmission under the following conditions:
• The channel is in mute condition.
• Channel is busy.
• A matched/non-matched CTCSS code is received.
• The selected channel is a ‘receive only’ channel.
• Time-out timer
After continuous transmission for a pre-programmed period,
the time-out timer is activated causing the transceiver to stop
transmitting and automatically select receive.
• Penalty timer
Once the time-out timer is activated, transmission is further
inhibited for a period determined by the penalty timer.
