Icom IC-F121S [12/20] Connection and maintenance
![Icom IC-F121S [12/20] Connection and maintenance](/views2/1074519/page12/bgc.png)
9
3
CONNECTION AND MAINTENANCE
Optional cable
(OPC-617)
q Antenna
NEVER connect to
a 24 V battery.
+
red:
black:
12V
Battery
Solder
Crimp
NOTE: Use the terminals as
shown below for the cable
connections.
R CAUTION! NEVER re-
move the fuse-holder from
the DC power cable.
e
r
t
w
To the antenna
connector
Optional speaker
(SP-22)
■ Rear panel and connection
IC-F111S_F121S_F211S_F221S 02.10.3 11:54 AM Page 9 (1,1)
