PANEL DESCRIPTION
¡¡
EMERGENCY KEY
Push and hold the key to transmit an emergency call.
• If you want to cancel the emergency call, push
and hold (or push) the key again before trans-
mitting the call.
• Depending on the pre-setting, the emergency
call is transmitted one time only, or repeatedly,
until receiving a control code.
¡¡
Hook Scan
Several functions are available for the hanger
function when taking the microphone from its
hanger (hanger-off) and/or returning it to the
hanger (hanger-on).
¡¡
USER SET MODE KEY
Changes the contents of the items in the User Set
mode. Please refer to p. 8.
• Push and hold this key for 1 sec. to enter set
mode. Push this key again momentarily to select
the desired item. Push [P2] and [P3] to set the
desired level/condition.
Push and hold this key again to exit set mode.
• User set mode also available via the ‘Power ON
function’.
¡¡
SCRAMBLER KEY
• Push and hold to turn the voice scrambler func-
tion ON.
• Push this key to turn the voice scrambler func-
tion OFF.
NOTE:
• The optional UT-109 (#02) or UT-110 (#02)
VOICE SCRAMBLER UNIT is required.
– UT-109: Non-rolling type. 32 codes are available.
– UT-110: Rolling type. Provides higher communi-
cation security. 1020 (4 groups × 255) codes are
available.
• This transceiver requires version #02 of
these units. Do not install version #01, as
they are not compatible.
• Some PC board modifications are required
when installing UT-109 and UT-110. Please
refer to ‘Optional UT-109/UT-110 installation’.
(p.12)
• Please contact your Dealer for details.
EMER
SCRM
HOOK
SET
