USE the supplied microphone only. Other microphones

have different pin assignments and may damage the trans-

ceiver.

DO NOT use or place the transceiver in areas with tempera-

tures below –22°F (–30°C) or above +140°F (+60°C), or in areas

subject to direct sunlight, such as the dashboard of a vehicle.

AVOID operating the transceiver without running the vehi-

cle’s engine. The vehicle’s battery will quickly run out if the

transceiver is in transmission while the vehicle’s engine OFF.

AVOID placing the transceiver in excessively dusty envi-

ronments.

AVOID placing the transceiver against walls. This will

obstruct heat dissipation.

AVOID the use of chemical agents such as benzine or alco-

hol when cleaning, as they damage the transceiver surfaces.

For U.S.A. only

CAUTION: Changes or modifications to this transceiver, not ex-

pressly approved by Icom Inc., could void your authority to operate

this transceiver under FCC regulations.

TABLE OF CONTENTS

IMPORTANT .................................................................................... i

EXPLICIT DEFINITIONS ................................................................. i

PRECAUTION .................................................................................. i

TABLE OF CONTENTS .................................................................. ii

1 PANEL DESCRIPTION ........................................................... 1–5

■ Front panel ............................................................................... 1

■ Function LED ........................................................................... 2

■ Programmable function keys .................................................... 3

2 OPERATION ............................................................................ 6–8

■ Turning power ON .................................................................... 6

■ Channel selection ..................................................................... 6

■ Receiving and transmitting ....................................................... 7

D Transmitting notes ................................................................. 7

D Scrambler function ................................................................ 8

D User set mode ....................................................................... 8

3 CONNECTION AND MAINTENANCE .................................. 9–13

■ Rear panel and connection ...................................................... 9

■ Supplied Accessories ............................................................. 10

■ Mounting the transceiver ......................................................... 11

■ Optional UT-108 installation ................................................... 11

■ Optional UT-109/UT-110 installation ...................................... 12

■ Optional OPC-617 installation................................................. 12

■ Antenna ................................................................................... 13

■ Fuse replacement .................................................................. 13

■ Cleaning ................................................................................. 13

4 OPTIONS ................................................................................... 14

5 SAFETY TRAINING INFORMATION ........................................ 15
