Icom IC-M402 [27/50] Set mode
![Icom IC-M402 [27/50] Set mode](/views2/1074653/page27/bg1b.png)
21
8
SET MODE
ïï
Dual/tri watch
This item can be selected
as dualwatch or tri-watch.
(p. 8)
ïï
DSC watch
DSC watch monitors Ch 70
while you are receiving an-
other channel.
If a distress signal is received on Ch 70, the transceiver
monitors Ch 16 and Ch 70 alternately until the distress signal
disappears. If a signal is received on another channel, DSC
watch pauses until the signal disappears.
This function may not be available for some channel
groups depending on dealer setting.
ïï
Beep tone
You can select silent oper-
ation by turning beep
tones OFF or you can
have confirmation beeps
sound at the push of a switch by turning beep tones ON.
ïï
LCD contrast
This item adjusts the contrast of the LCD in
4 steps.
Dual watch (default)
Tri-watch
DSC watch OFF
DSC watch ON (default)
Beep tone ON (default) Beep tone OFF
LCD contrast 3 (default)
00_IC-M402_S.qxd 02.2.21 0:08 PM Page 21 (1,1)
