33
10
HM-127 REMOTE-CONTROL MICROPHONE
■ Starting a scan
q Push [CH/WX•U/I/C] several times while pushing [H/L] to
select the channel group (USA, INT, CAN), if desired.
•When the weather alert function is in use, select the desired
weather channel with [CH/WX] and [Y]/[Z].
w Push [SCN] to start priority or normal scan.
•“SCAN” appears during normal scan.
•The priority channel readout indicates “16”, and “P” and “SCAN”
indicators appear during priority scan.
•When a signal is received, scan pauses until the signal disap-
pears or resumes after pausing 5 sec. according to set mode set-
ting (Ch 16 is still monitored during priority scan).
•Push [Y]/[Z] to check the scanning tag channels, to change the
scanning direction or resume the scan manually.
e To stop the scan, push [SCN].
•“SCAN” disappears.
•Pushing [PTT], [16•9] or [CH/WX] also stops the scan.
■ Setting tag channels
q Push [CH/WX•U/I/C] several times while pushing [H/L] to
select the channel group (USA, INT, CAN), if desired.
w Push [Y]/[Z] to select the desired channel to set as a tag
channel.
e Push [SCN•TAG] for 1 sec. to set the displayed channel as
a tag channel.
•“ ” appears.
r To cancel the tag channel setting, push and hold
[SCAN•TAG] for 1 sec.
•“ ” disappears.
• Clearing all tag channels in the selected channel group
➥ While pushing [Y] and [Z], Turn power ON to clear all tag
channels in the channel group.
■ Dualwatch/Tri-watch operation
q Push [Y]/[Z] to select the desired channel.
•Push [CH/WX•U/I/C] several times while pushing [H/L] to select
the channel group (USA, INT, CAN), if desired.
w Push [CH/WX•DW] for 1 sec. to start dualwatch or tri-
watch.
•“DUAL” appears during dualwatch; “TRI” appears during tri-
watch.
•Beep tone sounds when a signal is received on Channel 16.
•Tri-watch becomes dualwatch when receiving a signal on the call
channel.
e To cancel dualwatch/tri-watch, push [CH/WX•DW] again.
00_IC-M402_S.qxd 02.2.21 0:08 PM Page 33 (1,1)
