MSI MAG B460 TORPEDO [14/174] Specifications

Specifications

CPU

Supports 10th Gen Intel® Core™ and Pentium® Gold /

Celeron® processors for LGA 1200 socket*

* Please go to www.intel.com for more compatibility information.

* Onboard graphics output are disabled when using F SKU processors.

Chipset Intel® B460 Chipset

Memory

∙ 4x DDR4 memory slots, support up to 128GB*

∙ Intel® Core™ i7/ i9

▪ Supports up to DDR4 2933 MHz

∙ Intel® Core™ i5 and below

▪ Supports up to DDR4 2666 MHz

∙ Supports Dual-Channel mode

∙ Supports non-ECC, un-buffered memory

∙ Supports Intel® Extreme Memory Profile (XMP)

* Please refer www.msi.com for more information on compatible memory.

Expansion Slot

∙ 1x PCIe 3.0 x16 slot (From CPU, PCI_E1), supports x16

mode

∙ 1x PCIe 3.0 x16 slot (From PCH, PCI_E3), supports x4

mode*

∙ 2x PCIe 3.0 x1 slots (From PCH)

* PCI_E3 will be unavailable when installing M.2 SSD in the M2_2 slot.

Onboard Graphics

∙ 1x HDMI port, supports a maximum resolution of

4096x2160 @30Hz

∙ 1x DisplayPort, supports a maximum resolution of

4096x2304 @60Hz

Audio

∙ Realtek® ALC1200 Codec

▪ 7.1-Channel High Definition Audio

▪ Supports S/PDIF output

LAN ∙ 1x Realtek® RTL8125B 2.5Gbps LAN controller

Continued on next page
