– 9 –
CE-50 / CE-75 / TE-50 / TE-75 / TE-75S / TE-125 / TE-125BF
EN
DRAFT
ONLY
Electrical connection
Connect disposer to appropriate
household current only.
The receptacle to which this appliance is connected
must be controlled by a switch.
WARNING: Improper connection of the
equipment-earthing conductor can result in a
risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to
whether the appliance is properly earthed. Do not
modify the plug provided with the appliance if it will
not fit the outlet. Have a proper outlet installed by
a qualified electrician.
Earthing instructions
FOR WASTE DISPOSERS EQUIPPED WITH AN
EARTHED PLUG-IN POWER CORD
This appliance must be earthed. In the event of
a malfunction or breakdown, earthing provides
a path of least resistance for electric current to
reduce the risk of electric shock. This appliance
is equipped with a cord having an equipment-
grounding conductor and a grounding plug.
The plug must be plugged into an appropriate
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
If the supply cord is damaged it must be replaced
by the manufacturer, its service agent or similarly
qualified person in order to avoid a hazard.
Removing an attached power cord or plug voids
the warranty.
The following UK Electrical Section is for United
Kingdom only - skip if not applicable.
WHEN USING THE ATTACHED PRE-WIRED MOULDED
PLUG AND LEAD (fig. 3A)
9 These disposers are engineered to be connected
to a 220/240 V~-50/60 Hz electrical supply
through the attached three-pin plug and into a
wired socket.
9 The disposer must be protected by a BS 1363 13
Amp fuse. The fuse is included within the molded
plug and lead, attached to the disposer.
9 The 13 Amp double pole switched spur switch
should be positioned higher than the sink
countertop and at a minimum of one meter from
the side of the sink, away from water splashes
and out of the reach of children. This spur switch
must be a double pole with at least 3 mm contact
separation in each pole. 20 Amp DP switches BS
3676 meet this condition.
9 To avoid accidentally leaving the disposer running,
a switch with a neon indicator lamp is suggested.
9 A 13 Amp ASTA approved fuse, to BS 1363 must
be fitted in the fuse carrier of this spur switch.
ELECTRICAL CONNECTIONS:
Simply insert the plug into the socket wired as
previously described.
WHEN NOT USING THE PRE-WIRED PLUG BUT
WIRING DIRECT WITH FIXED WIRING (fig. 3B).
9 The switches used must be double pole type and
have at least a 3 mm contact separation in each
pole (20 Amp DP switches to BS 3676 meet this
requirement).Prepare the tips of the wires of the
electrical lead and attach to the junction box.
9 Disconnect the junction box from the electrical
supply before making the following connections:
9 The green and yellow wire must be connected to
the terminal marked in one of the following ways:
– with the letter “E”
– by the earth symbol (
)
– coloured green or green and yellow.
9 The brown wire must be connected to the
terminal that is marked with the letter „L“.
9 The blue wire must be attached to the terminal
that is marked with the letter „N“.
(NOTE: As your disposer has a molded plug on the
lead and the plug is not to be used, cut it off and
dispose of it wisely. A moulded plug with a loose
lead with disconnected wires can be hazardous as
an electrical shock hazard could occur should such
a plug be inserted into a 13 Amp socket anywhere
within the home.)
IS THE DISPOSER EARTHED?
WARNING: this appliance must be earthed!
In the event of a malfunction of breakdown,
earthing reduces the risk of shock. This disposer
must be connected to an earthed, metal, permanent
wiring conductor and connected to the equipment
earthing terminal or lead on the disposer.
