8
raised rear end of the sliding switch (2)
(switch position "0").
Avoid inadvertent starts: always switch the
tool off when the plug is removed from the
mains socket or if there has been a power cut.
7.3 Working With the Machine
• Always switch on the machine before offering up
to the workpiece.
• Guide the machine so that the blade (7) in the
cutting base is parallel with the workpiece.
• Guide the machine forwards without using
excessive force.
• When cutting to the edge of sheet material
(particularly when cutting along a scribe line),
guide the machine so that the cutting base (10) is
positioned on top (i.e. the machine upright with
the blade in the ram below the workpiece).
Pull the plug out of the plug socket before any
adjustments or servicing are performed.
8.1 Blades
The blades have four sharp cutting edges If one
edge becomes blunt, rotate the blades 90° to use
the next sharp edge.
The blades are not designed to be sharpened.
Replace the blades when all four cutting
edges are blunt.
Never work with blunt blades!
Replacing the blades, see Section 9.
(Accessories).
Blade (6) in the ram:
- Only for Ku 6870:
Unscrew the screw for attaching the cutting base
(4) and remove the cutting base (10).
- Unscrew the screw (5).
- Remove the blade (6), rotate 90° and insert again
(so that the one cutting edge rests against the
angled face of the ram).
- Tighten the screw (5) again.
- Only for Ku 6870: Attach the cutting base (10)
again and secure with the cutting base screw (4).
Blade (7) in the cutting base:
- Unscrew the screw (9).
- Remove the blade (7), rotate 90° and insert again.
- Adjust the distance between the blades and
secure the blade (7) again (see Section 7.1).
8.2 Carbon Brushes
If the brushes are completely worn, the machine
switches off automatically. This prevents damage to
the motor.
The carbon brushes should be replaced by the
manufacturer or a suitable specialist workshop. See
Section10. (Repairs).
Use only genuine Metabo accessories.
If you need any accessories, check with your
dealer.
For dealers to select the correct accessory, they
need to know the exact model designation of your
power tool.
A Replacement reversible blades
(same blade for ram and cutting base)
Order no. for Ku 6870: 6.30201
Order no. for Ku 6872: 6.31042
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out
by qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
The sanding dust generated may contain
hazardous materials: do not dispose of with the
household waste, but at a special collection point
for hazardous waste.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
handed in for environmentally compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
M=Torque
B
St
=Maximum sheet thickness
(sheet steel)
B
Al
=Maximum sheet thickness (aluminium)
P
1
=Nominal power input
P2 =Power output
h
0
=Stroke rate at idle speed
h
1
=Stroke rate at rated load
r
min
=Smallest curve radius
m =Weight without mains cable
Measured values determined in conformity with
EN 60745.
Machine in protection class II
~ Alternating current
8. Maintenance
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Specifications
