Piping Diagrams Si12-308A
266 Appendix
FVK(X)S50BVMB
1.1.4 Floor / Ceiling Suspended Dual Type
FLK(X)S 25/35/50/60 BVMB
FIELD PIPING
FIELD PIPING
(
12.7CuT
)
(
6.4CuT
)
REFRIGERANT FLOW
INDOOR UNIT
9.5CuT
MUFFLER
MUFFLER
CROSS FLOW FAN
CROSS FLOW FAN
HEATING
COOLING
FAN MOTOR
FAN MOTOR
9.5CuT
M
M
4.8CuT
4.8CuT
7.0CuT
HEAT EXCHANGER
7.0CuT
7.0CuT
7.0CuT
ON HEAT EXCH.
THERMISTOR
4D020911B
FIELD PIPING
FIELD PIPING
(
(
6.4CuT
)
CuT
)
INDOOR UNIT
SIROCCO FAN
REFRIGERANT FLOW
(
FAN MOTOR
(
CuT
)
M
CuT
)
HEATING
COOLING
HEAT EXCHANGER
THERMISTOR
ON HEAT
EXCH.
FLX25
,
35-
FLK25
,
35-
FLXS25
,
35-
FLKS25
,
35-
FLX50
,
60-
FLK50
,
60-
FLXS50
,
60-
FLKS50
,
60-
12.7
9.5
12.7
9.5
4D034012B
6.4
9.5
