Si12-308A Specifications
Specifications 55
Floor Standing Type
50Hz 230-240V
Model
FVXS25BVMB FVXS35BVMB
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color Almond White Almond White
Air Flow Rates
m³/min
(cfm)
H 8.1 (286) 9.2 (325) 8.3 (293) 9.2 (325)
M 6.2 (219) 7.0 (247) 6.3 (222) 7.1 (251)
L 4.3 (152) 4.8 (169) 4.3 (152) 5.0 (177)
SL 3.4 (120) 3.5 (124) 3.4 (120) 3.6 (127)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 14 + 14 14 + 14
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Upward Right, Left, Horizontal and Upward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.14 0.14 0.14 0.14
Power Consumption (Rated) W 32 32 32 32
Power Factor % 99.4 99.4 99.4 99.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 600×650×195 600×650×195
Packaged Dimension mm 770×294×714 770×294×714
Weight kg 13 13
Gross Weight kg 19 19
Operation
Sound
H/M/L/SL dBA 38/32/26/23 38/32/26/23 39/33/27/24 39/34/29/26
Sound Power H dBA 54
—
55
—
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
9.5
Drain mm
φ
26.0
φ
26.0
Drawing No. 3D040172A 3D040173A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FVXS50BVMB
Cooling Heating
Rated Capacity 5.0kW Class
Front Panel Color Almond White
Air Flow Rates
m³/min
(cfm)
H 10.8 (381) 13.2 (466)
M 9.2 (325) 11.3 (399)
L 7.7 (272) 9.4 (332)
SL 6.7 (237) 8.3 (293)
Fan
Type Cross Flow Fan
Motor Output W 14 + 14
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Upward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.26-0.25 0.32-0.31
Power Consumption (Rated) W 55-55 70-70
Power Factor % 92.0-91.7 95.1-94.1
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 600×650×195
Packaged Dimension mm 770×294×714
Weight kg 13
Gross Weight kg 19
Operation
Sound
H/M/L/SL dBA 44/40/36/33 45/40/36/33
Sound Power H dBA 56 57
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
Gas mm
φ
12.7
Drain mm
φ
26.0
Drawing No. 3D040831, 3D040832
