Si12-308A Specifications
Specifications 41
1.3 Indoor Units - Heat Pump
Wall Mounted Type
50Hz 220V
Model
FTXE25BVMC FTXE35BVMC
Cooling Heating Cooling Heating
Rated Capacity 2.5kW Class 3.5kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 7.8 (275) 8.1 (286) 7.7 (272) 8.1 (286)
M 6.4 (226) 6.6 (233) 6.3 (222) 6.6 (233)
L 5.0 (177) 5.1 (180) 4.9 (173) 5.1 (180)
SL 4.3 (152) 4.3 (152) 4.4 (155) 4.4 (155)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 18 18
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.17 0.17 0.17 0.17
Power Consumption (Rated) W 37 37 37 37
Power Factor % 98.9 98.9 98.9 98.9
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 273×784×195 273×784×195
Packaged Dimensions (W×D×H) mm 834×325×258 834×325×258
Weight kg 7.5 7.5
Gross Weight kg 11 11
Operation
Sound
H/M/L/SL dBA 37/34/30/27 37/34/30/27 38/37/32/29 38/35/31/28
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
9.5
φ
12.7
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D041253 3D041254
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
Model
FTXD50BVMC FTXD60BVMC
Cooling Heating Cooling Heating
Rated Capacity 5.0kW Class 6.0kW Class
Front Panel Color White White
Air Flow Rates
m³/min
(cfm)
H 12.3 (434) 12.5 (441) 17.5 (617) 18.7 (660)
M 10.4 (367) 11.0 (388) 14.6 (517) 16.1 (567)
L 8.7 (307) 9.6 (339) 12.2 (431) 13.6 (481)
SL 7.7 (272) 8.2 (289) 10.8 (383) 11.8 (418)
Fan
Type Cross Flow Fan Cross Flow Fan
Motor Output W 40 43
Speed Steps 5 Steps, Silent and Auto 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof Removable-Washable-Mildew Proof
Running Current (Rated) A 0.21 0.23 0.21 0.21
Power Consumption (Rated) W 45 50 45 45
Power Factor % 97.4 98.8 97.4 97.4
Temperature Control Microcomputer Control Microcomputer Control
Dimensions (H×W×D) mm 290×795×238 290×1,050×238
Packaged Dimensions (W×D×H) mm 840×338×280 1,147×366×337
Weight kg 9 12
Gross Weight kg 13 17
Operation
Sound
H/M/L/SL dBA 44/39/35/32 42/37/33/30 45/41/36/33 44/40/35/32
Heat Insulation Both Liquid and Gas Pipes Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
6.4
φ
6.4
Gas mm
φ
12.7
φ
15.9
Drain mm
φ
18.0
φ
18.0
Drawing No. 3D040805 3D040806
