Specifications Si12-308A
46 Specifications
60Hz 220V
Model
FTXD71BVMT
Cooling Heating
Rated Capacity 7.1kW Class
Front Panel Color White
Air Flow Rates
m³/min
(cfm)
H 16.6 (585) 18.2 (642)
M 13.9 (490) 15.7 (553)
L 11.7 (412) 13.3 (469)
SL 10.4 (368) 11.7 (412)
Fan
Type Cross Flow Fan
Motor Output W 43
Speed Steps 5 Steps, Silent and Auto
Air Direction Control Right, Left, Horizontal and Downward
Air Filter Removable-Washable-Mildew Proof
Running Current (Rated) A 0.23 0.23
Power Consumption (Rated) W 50 50
Power Factor % 98.8 98.8
Temperature Control Microcomputer Control
Dimensions (H×W×D) mm 290×1,050×238
Packaged Dimension mm 1,147×366×337
Weight kg 12
Gross Weight kg 17
Operation
Sound
H/M/L/SL dBA 46/42/37/34 46/42/37/34
Heat Insulation Both Liquid and Gas Pipes
Piping Connection
Liquid mm
φ
9.5
Gas mm
φ
15.9
Drain mm
φ
18.0
Drawing No. 3D040810A
Conversion Formulae
kcal/h=kW×860
Btu/h=kW×3414
cfm=m³/min×35.3
