xi
Configuration 1 2
A
PCIEX16_1 x16 x8
PCIEX16_2 - x4
Configuration 1 2
B
PCIEX16_3 x4 x1
PCIEX1_1 - x1
PCIEX1_2 - x1
PCIEX1_3 - x1
Configuration 1 2
C
M.2_1 PCIe 3.0 x4 / SATA -
SATA6G_56 - V
Configuration 1 2
D
M.2_2 - PCIe 3.0 x4
PCIEX16_1 x16 x8
Configuration 1
A
PCIEX16_1 x8
PCIEX16_2 -
Configuration 1 2
B
PCIEX16_3 x4 x1
PCIEX1_1 - x1
PCIEX1_2 - x1
PCIEX1_3 - x1
Configuration 1 2
C
M.2_1 PCIe 3.0 x4 / SATA -
SATA6G_56 - V
Configuration 1
D
M.2_2 -
PCIEX16_1 x8
3
rd
/2
nd
/1
st
Gen AMD Ryzen™ Processors
2
nd
and 1
st
Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors
