Asus ROG STRIX B450-F GAMING II [13/70] Installation tools and components

xiii

Installation tools and components

Phillips (cross) screwdriver

PC chassis Power supply unit

AMD AM4 CPU AMD AM4/AM3 compatible CPU Fan

DDR4 DIMM SATA hard disk drive

SATA optical disc drive (optional) Graphics card (optional)

M.2 SSD module (optional) 1 Bag of screws

The tools and components in the table above are not included in the motherboard

package.
