Asus ROG STRIX B450-F GAMING II [42/70] Chapter 2

2-4

Chapter 2: Basic Installation

Chapter 2

AIO_PUMP

CPU_OPT

CPU_FAN

To install an AIO cooler

If you wish to install an AIO cooler, we recommend installing the AIO cooler after installing

the motherboard into the chassis.
