Asus ROG STRIX B450-F GAMING II [19/70] Chapter 1

ROG STRIX B450-F GAMING II

1-5

Chapter 1

2. DIMM slots

The motherboard comes with Dual Inline Memory Modules (DIMM) slots designed for DDR4

(Double Data Rate 4) memory modules.

A DDR4 memory module is notched differently from a DDR, DDR2, or DDR3 module. DO

NOT install a DDR, DDR2, or DDR3 memory module to the DDR4 slot.

Recommended memory configurations
