Asus ROG STRIX B450-F GAMING II [41/70] Chapter 2

ROG STRIX B450-F GAMING II

2-3

Chapter 2

CPU heatsink and fan assembly Type 2

When using this type of CPU fan, remove the screws and the retention module only. Do

not remove the plate on the bottom.
