Asus ROG STRIX B450-F GAMING II [6/70] Rog strix b450 f gaming ii specifications summary
![Asus ROG STRIX B450-F GAMING II [6/70] Rog strix b450 f gaming ii specifications summary](/views2/1769516/page6/bg6.png)
vi
ROG STRIX B450-F GAMING II specifications summary
CPU
AMD Socket AM4 for 3
rd
/2
nd
/1
st
Gen AMD Ryzen™/ 2
nd
and 1
st
Gen AMD
Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega
Graphics Processors*
* Refer to www.asus.com for CPU support list.
Chipset
AMD B450 Chipset
Memory
3
rd
/2
nd
/1
st
Gen AMD Ryzen™/ 2
nd
and 1
st
Gen AMD Ryzen™ with
Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics
Processors
4 x DIMM, Max. 128GB, DDR4 4400(O.C.) / 4000(O.C.) / 3866(O.C.) /
3600(O.C.) / 3466(O.C.) / 3200 / 3000 / 2800 / 2666 / 2400 / 2133
MHz Non-ECC, Un-buffered Memory*
Dual channel memory architecture
* Refer to www.asus.com for the Memory QVL (Qualified Vendors Lists).
Graphics
1 x DisplayPort 1.2
1 x HDMI™ 2.0b
Expansion Slots
3
rd
/2
nd
/1
st
Gen AMD Ryzen™ Processors
2 x PCIe 3.0 x16 slots (support x16 or x8 / x4 modes)
2
nd
and 1
st
Gen AMD Ryzen™ with Radeon™ Vega Graphics
Processors
1 x PCIe 3.0 x16 slot (supports x8 mode)
Athlon™ with Radeon™ Vega Graphics Processors
1 x PCIe 3.0 x16 slot (supports x4 mode)
AMD B450 chipset
1 x PCIe 2.0 x16 slot (supports x4 mode)*
3 x PCIe 2.0 x1 slots
* PCIe x16_3 slot shares bandwidth with PCIe x1_1, PCIe x1_2, and PCIe x1_3.
Multi-GPU Support
Supports AMD 3-way CrossFireX™ Technology
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
3
rd
/2
nd
/1
st
Gen AMD Ryzen™ Processors
M.2_1 slot (Key M), type 2242/2260/2280
(supports PCIe 3.0 x4 & SATA modes)*
M.2_2 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 3.0 x4 mode)**
2 x SATA 6Gb/s ports
2
nd
and 1
st
Gen AMD Ryzen™ with Radeon™ Vega Graphics
Processors
M.2_1 slot (Key M), type 2242/2260/2280
(supports PCIe 3.0 x4 & SATA modes)
2 x SATA 6Gb/s ports
Athlon™ with Radeon™ Vega Graphics Processors
M.2_1 slot (Key M), type 2242/2260/2280
(supports PCIe 3.0 x2 & SATA modes)
2 x SATA 6Gb/s ports
(continued on the next page)
