Asus ROG STRIX B450-F GAMING II [21/70] Chapter 1

ROG STRIX B450-F GAMING II

1-7

Chapter 1

3. Expansion slots

Unplug the power cord before adding or removing expansion cards. Failure to do so may

cause you physical injury and damage motherboard components.

Please refer to the following tables for the recommended VGA configuration and Hyper M.2

configuration.
