Asus ROG STRIX B450-F GAMING II [32/70] Chapter 1

1-18

Chapter 1: Product Introduction

Chapter 1

13. COM Port connector

The COM (Serial) Port connector allows you to connect a COM port module. Connect

the COM port module cable to this connector, then install the module to a slot opening

on the system chassis.

The COM port module is purchased separately.
