ESIE15-13C Troubleshooting by Remote Controller
Service Diagnosis 187
Outdoor unit
T°C kΩ T°C kΩ T°C kΩ T°C kΩ T°C kΩ T°C kΩ
0 640.44 0.5 624.65 50 72.32 50.5 70.96 100 13.35 100.5 13.15
1 609.31 1.5 594.43 51 69.64 51.5 68.34 101 12.95 101.5 12.76
2 579.96 2.5 565.78 52 67.06 52.5 65.82 102 12.57 102.5 12.38
3 552.00 3.5 538.63 53 64.60 53.5 63.41 103 12.20 103.5 12.01
4 525.63 4.5 512.97 54 62.24 54.5 61.09 104 11.84 104.5 11.66
5 500.66 5.5 488.67 55 59.97 55.5 58.87 105 11.49 105.5 11.32
6 477.01 6.5 465.65 56 57.80 56.5 56.75 106 11.15 106.5 10.99
7 454.60 7.5 443.84 57 55.72 57.5 54.70 107 10.83 107.5 10.67
8 433.37 8.5 423.17 58 53.72 58.5 52.84 108 10.52 108.5 10.36
9 413.24 9.5 403.57 59 51.98 59.5 50.96 109 10.21 109.5 10.06
10 394.16 10.5 384.98 60 49.96 60.5 49.06 110 9.92 110.5 9.78
11 376.05 11.5 367.35 61 48.19 61.5 47.33 111 9.64 111.5 9.50
12 358.88 12.5 350.62 62 46.49 62.5 45.67 112 9.36 112.5 9.23
13 342.58 13.5 334.74 63 44.86 63.5 44.07 113 9.10 113.5 8.97
14 327.10 14.5 319.66 64 43.30 64.5 42.54 114 8.84 114.5 8.71
15 312.41 15.5 305.33 65 41.79 65.5 41.06 115 8.59 115.5 8.47
16 298.45 16.5 291.73 66 40.35 66.5 39.65 116 8.35 116.5 8.23
17 285.18 17.5 278.80 67 38.96 67.5 38.29 117 8.12 117.5 8.01
18 272.58 18.5 266.51 68 37.63 68.5 36.98 118 7.89 118.5 7.78
19 260.60 19.5 254.72 69 36.34 69.5 35.72 119 7.68 119.5 7.57
20 249.00 20.5 243.61 70 35.11 70.5 34.51 120 7.47 120.5 7.36
21 238.36 21.5 233.14 71 33.92 71.5 33.35 121 7.26 121.5 7.16
22 228.05 22.5 223.08 72 32.78 72.5 32.23 122 7.06 122.5 6.97
23 218.24 23.5 213.51 73 31.69 73.5 31.15 123 6.87 123.5 6.78
24 208.90 24.5 204.39 74 30.63 74.5 30.12 124 6.69 124.5 6.59
25 200.00 25.5 195.71 75 29.61 75.5 29.12 125 6.51 125.5 6.42
26 191.53 26.5 187.44 76 28.64 76.5 28.16 126 6.33 126.5 6.25
27 183.46 27.5 179.57 77 27.69 77.5 27.24 127 6.16 127.5 6.08
28 175.77 28.5 172.06 78 26.79 78.5 26.35 128 6.00 128.5 5.92
29 168.44 29.5 164.90 79 25.91 79.5 25.49 129 5.84 129.5 5.76
30 161.45 30.5 158.08 80 25.07 80.5 24.66 130 5.69 130.5 5.61
31 154.79 31.5 151.57 81 24.26 81.5 23.87 131 5.54 131.5 5.46
32 148.43 32.5 145.37 82 23.48 82.5 23.10 132 5.39 132.5 5.32
33 142.37 33.5 139.44 83 22.73 83.5 22.36 133 5.25 133.5 5.18
34 136.59 34.5 133.79 84 22.01 84.5 21.65 134 5.12 134.5 5.05
35 131.06 35.5 128.39 85 21.31 85.5 20.97 135 4.98 135.5 4.92
36 125.79 36.5 123.24 86 20.63 86.5 20.31 136 4.86 136.5 4.79
37 120.76 37.5 118.32 87 19.98 87.5 19.67 137 4.73 137.5 4.67
38 115.95 38.5 113.62 88 19.36 88.5 19.05 138 4.61 138.5 4.55
39 111.35 39.5 109.13 89 18.75 89.5 18.46 139 4.49 139.5 4.44
40 106.96 40.5 104.84 90 18.17 90.5 17.89 140 4.38 140.5 4.32
41 102.76 41.5 100.73 91 17.61 91.5 17.34 141 4.27 141.5 4.22
42 98.75 42.5 96.81 92 17.07 92.5 16.80 142 4.16 142.5 4.11
43 94.92 43.5 93.06 93 16.54 93.5 16.29 143 4.06 143.5 4.01
44 91.25 44.5 89.47 94 16.04 94.5 15.79 144 3.96 144.5 3.91
45 87.74 45.5 86.04 95 15.55 95.5 15.31 145 3.86 145.5 3.81
46 84.38 46.5 82.75 96 15.08 96.5 14.85 146 3.76 146.5 3.72
47 81.16 47.5 79.61 97 14.62 97.5 14.40 147 3.67 147.5 3.62
48 78.09 48.5 76.60 98 14.18 98.5 13.97 148 3.58 148.5 3.54
49 75.14 49.5 73.71 99 13.76 99.5 13.55 149 3.49 149.5 3.45
50 72.32 50.5 70.96 100 13.35 100.5 13.15 150 3.41 150.5 3.37
RZQG Thermistor
R2T Discharge pipe thermistor
